10. INSTALLATION METHOD
15
Installation steps:
1. Punching in the wall.
2. Insert the rubber particle of M8 into
the hole.
3. Align the hole position of the fixed
panel to the hole of the rubber particle.
4. Fix the screw of M4*35 of panel.
5. The machine need to be locked in the
fixed plate and fixed the lower end of
panel with screw.
①
②
③
The fixed panel
Equipment
The rubber particle
The screw
