iTechworld SOLAR BLANKET 200W - How To Use; Connecting The Solar Blanket; Disconnecting The Solar Blanket

Extend the solar blanket (1).
Fold out the built-in stand.
Point the solar cells towards the sun at the optimum angle.
Connect the battery clamps (4) onto your battery.
Connect the solar controller (2) to your battery using the
Anderson plug on the opposite end of the battery clamps (4).
Connect the solar blanket (1) to the solar controller using the
5M extension lead (3) if required.
1.
2.
3.
4.
5.
6.
How To Use
Connecting Steps
Disconnect the solar blanket (1) from the solar controller (2).
Disconnect the solar controller (2) from the battery clamps (4).
Disconnect the battery clamps (4) from your battery.
Fold up the solar blanket (1) as shown on the following page.
Store the accessories in the bag on the solar blanket (1).
1.
2.
3.
4.
5.
Disconnecting Steps
