ITRON Delta Series User Manual

63
Annex 1: Recommended installation / Installation recommandée / Empfohlene Installation / Installazione raccomandata /
Instalaciones recomendadas / Installatie voorschrift / Tavsiye edilen döşeme / Instalação Recomendada / Doporučený způsob
instalace
D
L
Flange meters with holes threaded
Face of the flange




 

Noinstallationatlowpointinthenetwork
Installationfreeoftensions
Impellersmustbehorizontalprocessioned
Visualinspectionatthereception
Notweldingtheinstalledmeter

ITRON Delta Series Specifications

General

Display	LCD with backlight
Operating Temperature	-10°C to +55°C
Storage Temperature	-25°C to +70°C
Current Range	5A to 100A (direct connection), higher with CTs
Frequency Range	45Hz to 65Hz
Communication Interface	RS485
