6. Best practice is to now lock the tablet in place. See Locking and Unlocking the Dock on
page 24.
Attach a Laptop to the Vehicle Dock
1. Ensure the dock is unlatched by observing that the latch button on the front of the dock is
recessed.
2. Holding the laptop at the top, angle the front edge of the laptop into the dock toward the latch
button.
3. Slowly lower the back of the laptop onto the dock, ensuring that the laptop connectors and
the dock connectors are aligned. The back of the laptop and the two dock latch hooks should
07 May 2020 815-0207-00 REV 000 Itron, Inc. Page 23 of 44
Vehicle Preparation and Hardware Installation Guide 3 Installing Mobile Collection Components
