2. Unlock the dock by inserting the dock key into the dock lock and turning it counterclockwise
until the lock is in the unlocked position.
Tilting and Swiveling the Dock
The tilt and swivel mechanisms operate the similarly on tablet and laptop docks. A tablet dock is
shown below as an example.
07 May 2020 815-0207-00 REV 000 Itron, Inc. Page 25 of 44
Vehicle Preparation and Hardware Installation Guide 3 Installing Mobile Collection Components
