IVEK DIGISPENSE 3009 - Page 10

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-10
29 October, 2019 IVEK Corp. P03R017E
Screen Description
Change Permission Allows changing the Permission level.
Dispense Displays total strokes, cycles, and allows changing volume, recipe, direction, rate and
drawback settings.
Drawback Allows changing drawback volume, drawback rate and drawback dwell.
Enter New Value Used for entering a numerical value.
Fault Displays the current fault if present.
Meter Displays total strokes, cycles, and allows changing recipe, direction, rate and draw-
back settings.
Power up Displays the controller type.
Prime Allows changing recipe, direction, rate and duration.
Recipe Used for saving a new recipe or retrieving an existing recipe.
Select New Value Used for selecting a new value from a list.
Setup A Displays recipe #, Permission level and allows changing Mode, Auto Retrigger and
Production Dwells settings.
Warning Recipe Exists Appears when you try to save a recipe using a previously used number.
Table 3.1 Standard Screen Information
POWER UP SCREEN
PRIME SCREEN
DISPENSE or
DRAWBACK SCREEN
METER SCREEN
These screens open
when a recipe button is
pressed.
RECIPE SCREEN
WARNING RECIPE
EXISTS SCREEN
SETUP A SCREEN
CHANGE PERMISSION
SCREEN
This screen opens when
This screen opens when
you press Enter to select
you press Enter to change
a value from a list.
a numerical value.
SELECT NEW VALUE
ENTER NEW VALUE
SCREEN
SCREEN
This screen opens
when a fault occurs.
Returns to Setup A
screen.
FAULT SCREEN
Figure 3.3 Standard Use Screen Navigation
