DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-13
29 October, 2019 IVEK Corp. P03R017E
3.3.7.2 Prime Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 PRIME <— status —>
2
3 VOLUME PRIMED = ##,### STROKES
4
5
6 RECIPE = ##
7 PRIME DIRECTION = FORWARD
8 PRIME VOLUME = ##### STROKES
9 PRIMING RATE = #### RPM
10
11
12
13
if dispense mode
14 *DISPENSE SETUP A CHANGE GET
15 SCREEN SCREEN DIRECTION RECIPE
OR if disabled production mode
14 SETUP A CHANGE GET
15 SCREEN DIRECTION RECIPE
OR if NO motor/base selected
14 DISPENSE SETUP A SETUP C GET
15 SCREEN SCREEN SCREEN RECIPE
OR if reference required
14 DISPENSE SETUP A REFERENCE GET
15 SCREEN SCREEN RECIPE
OR if direction change disabled
14 DISPENSE SETUP A GET
15 SCREEN SCREEN RECIPE
OR if get recipe disabled
14 DISPENSE SETUP A CHANGE
15 SCREEN SCREEN DIRECTION
OR if direction change and get recipe disabled
14 DISPENSE SETUP A
15 SCREEN SCREEN
NOTE
* Field 3 will display DISPENSE SCREEN when in
Dispense mode or METER SCREEN when in Meter
mode.
----- Displays the Controller Module Status ........ D D D
----- Displays the volume dispensed during prime D D D
----- Displays the current recipe .......................... D D D
----- Display/change the prime direction ............. D D C
----- Display/change the prime duration .............. D D C
----- Display/change the priming rate .................. D D C
The following screens are accessible from
this screen based on the system status.
Dispense .............................................................. P P P
Change Direction ................................................. D D C
Get Recipe ........................................................... P P P
Meter .................................................................... P P P
Setup A ................................................................ P P P
Setup C ................................................................ P P P
