3.3.7.5 Setup A Screen
Keylock/ Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 SETUP A <— status —>
2
3 RECIPE = ##
4
5 PRODUCTION MODE = DISPENSE
6 FLUIDIC SETUP MODE = PRIME
7
8 AUTO RETRIGGER = DISABLED
9 PRODUCTION DWELLS = DISABLED
10 FRONT PANEL LOCK = DISABLED
11POWER-UP PERMISSION = LAST AT POWER OFF
12 CURRENT PERMISSION = OPERATOR
13
if prime mode
14 *PRIME SETUP B SAVE
15 SCREEN SCREEN RECIPE
OR if disabled production mode and fluidic setup mode
14 GET SETUP B SAVE
15 RECIPE SCREEN RECIPE
OR if dispense mode and disabled fluidic setup mode
14 *DISPENSE SETUP B SAVE
15 SCREEN SCREEN RECIPE
OR if faulted
14 GET SETUP B FAULT SAVE
15 RECIPE SCREEN SCREEN RECIPE
OR if prime mode and save recipe disabled
14 PRIME SETUP B
15 SCREEN SCREEN
NOTE
* Field 3 will display PRIME SCREEN when in Prime mode or
AGITATE SCREEN when in Agitate mode.
* When Fluidic Setup Mode is disabled, Field 3 will display
DISPENSE SCREEN when in Dispense mode or METER
SCREEN when in Meter mode.
----- Displays the Controller Module Status ........ D D D
----- Displays the current recipe .......................... D D D
----- Display/change the production mode .......... D D C
----- Display/change the fluidic setup mode ........ D D C
----- Display/change the auto retrigger setting .... D D C
----- Display/change the production dwells setting P P P
----- Display/change the front panel lock setting . D D *
----- Display/change the power up permission .... D D C
----- Display/change the current permission ....... D D C
The following screens are accessible from
this screen based on the system status.
Agitate .................................................................. P P P
Save Recipe ......................................................... P P P
Prime .................................................................... P P P
Setup B ................................................................ P P P
Dispense .............................................................. P P P
Meter .................................................................... P P P
Change Permission .............................................. P P P
* D for Supervisor
C for Keylock
