3.3.7.6 Drawback Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 DRAWBACK <— status —>
2
3
4 DRAWBACK VOLUME = #.## STROKES
5 DRAWBACK RATE = #### RPM
6 DRAWBACK DWELL = #.## SEC
7
8
9
10
11
12
13
14
15 BACK
----- Displays the Controller Module Status ........ D D D
----- Display/change the drawback volume ......... D D C
----- Display/change the drawback rate .............. D D C
----- Display/change the drawback dwell ............ D D C
----- Display/change the drawback dwell ............ N N P
