IVEK DIGISPENSE 3009 - Page 23

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-23
29 October, 2019 IVEK Corp. P03R017E
3.3.7.7 Select New Value and Enter New Value Screens
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 ENTER NEW VALUE
2
3 Value Label (units)
4 0############
5
6
7 ############# MAXIMUM
8 ############# MINIMUM
9
10 ############# INCREMENT
11
If help NOT pressed
12
13
If help pressed
12 Help message line 1 for value… *
13 Help message line 2 for value…*
14
15 HELP MINIMUM MAXIMUM CANCEL
Keylock/Supervisor
I/O Test
Operator
0 SELECT NEW VALUE
2
3 Value Label
4 Selection 1
5 Selection 2
6
7
8
9
10
11
If help NOT pressed
12
13
If help pressed
12 Help message line 1 for selection…*
13 Help message line 2 for selection…*
14
15 HELP CANCEL
* Indicated the list is too long to fit on the screen, the rest of the list can be accessed by using the Up or
Down buttons to scroll.
----- Displays the parameter to be changed ........ D D D
----- Display/change the value............................. D D C
----- Displays the maximum value ....................... D D D
----- Displays the minimum value ........................ D D D
----- Displays the increment value ....................... D D D
----- Returns to the previous screen .................... P P P
----- Sets the value to the maximum setting ........ P P P
----- Sets the value to the minimum setting ......... P P P
----- Displays information on selected value ....... P P P
----- Display/select the available values .............. D D C
----- Returns to the previous screen .................... P P P
----- Displays information on selected value ....... P P P
