Screen Description
Caution Cautions against certain actions
Change Password Allows changing the password.
Change Permission Allows changing the Permission level.
Clear Totalizer Clears the Total Volume and Total Cycles counters.
Dispense Displays total strokes, cycles, and allows changing volume, recipe, direc-
tion, rate and drawback settings.
Drawback Allows changing drawback volume, drawback rate and drawback dwell.
Enter New Password Used for changing an existing password.
Enter New Value Used for entering a numerical value.
Fault Displays the current fault if present.
FP Lock Displays the current front panel lock setting.
I/O Test Test the functionality of the Inputs and Outputs.
Meter Displays total volume, total cycles and allows changing recipe, direction,
rate and drawback settings.
Power up Displays the controller type.
Prime Allows changing recipe, direction rate, and prime volume.
Recipe Used for saving a new recipe or retrieving an existing recipe.
Reset Parameters Warnings Erases all recipes and resets passwords.
Select New Value Used for selecting a new value from a list.
Setup A Displays recipe #, Permission level and allows changing Mode, Auto
Retrigger and Production Dwells settings.
Setup B Allows changing Ready Output Config, Auxiliary Output, Output 3 Config,
Input 2 Config, Input 3, Input 4 and Output 4 settings.
Setup C Allows changing Motor/Base, Stalls per Fault, Stop Position, Torque and
Acceleration.
Setup D Allows changing RS232/RS485/USB baud rates and the Comm Address and
Gateway
Setup E Allows changing the LOGIC I/O Gateway and the state of a number of outputs
System Info Screen Displays firmware and assert information.
Warning Recipe Exists Appears when you try to save a recipe using a previously used number.
Table 3.2 Screen Information
