3.4.7.1 Power Up Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 DIGISPENSE 3009 <— status —>
2
3
4 IVEK CORPORATION
5 http://www.ivek.com
6
7 RECIPE = ##
8 MOTOR/BASE = #
9
10
11
12 Press function button below to proceed
13
if prime mode and dispense mode
14 *PRIME *DISPENSE CONTRAST
15 SCREEN SCREEN ADJUST
OR if dispense mode and disabled fluidic setup mode
14 DISPENSE CONTRAST
15 SCREEN ADJUST
OR if prime mode and disabled production mode
14 PRIME CONTRAST
15 SCREEN ADJUST
OR if disabled fluidic setup mode and production mode
14 SETUP A CONTRAST
15 SCREEN ADJUST
OR if NO motor/base selected
14 PRIME DISPENSE SETUP C CONTRAST
15 SCREEN SCREEN SCREEN ADJUST
OR if reference recommended
14 PRIME DISPENSE REFERENCE CONTRAST
15 SCREEN SCREEN ADJUST
OR if faulted
14 FAULT CONTRAST
15 SCREEN ADJUST
NOTE
* Field 3 will display PRIME SCREEN when in Prime
mode or AGITATE SCREEN when in Agitate mode.
* Field 4 will display DISPENSE SCREEN when
in Dispense mode or METER SCREEN when in
Meter mode.
----- Displays the Controller Module Status ........ D D D
----- Displays the current recipe .......................... D D D
----- Displays the motor/base selection ............... D D D
The following screens are accessible from
this screen based on the system status.
Agitate .................................................................. P P P
Contrast Adjust .................................................... P P P
Dispense .............................................................. P P P
Fault ..................................................................... P P P
Meter .................................................................... P P P
Prime .................................................................... P P P
Setup C ................................................................ P P P
