DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-47
29 October, 2019 IVEK Corp. P03R017E
3.4.7.5 Meter Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 METER <— status —>
2
3 TOTAL VOLUME = ########## STROKES
4 TOTAL CYCLES = ##########
5
6 RECIPE = ##
7 DIRECTION = FORWARD
8
9 DISPENSE/METER RATE = #### RPM
10 METER STOP = STOP POSITION
11
12 DRAWBACK = DISABLED
13
if prime mode
14 *PRIME SETUP A GET
15 SCREEN SCREEN RECIPE
OR if disabled fluidic setup mode
14 SETUP A GET
15 SCREEN RECIPE
OR if NO motor/base selected
14 PRIME SETUP A SETUP C GET
15 SCREEN SCREEN SCREEN RECIPE
OR if reference required
14 PRIME SETUP A REFERENCE GET
15 SCREEN SCREEN REQUIRED RECIPE
OR if get recipe disabled
14 PRIME SETUP A
15 SCREEN SCREEN
NOTE
* Field 3 will display PRIME SCREEN when in Prime mode or
AGITATE SCREEN when in Agitate mode.
----- Displays the Controller Module Status ........ D D D
----- Displays the total number of strokes ........... D D D
----- Displays the total number of cycles ............. D D C
----- Displays the current recipe .......................... D D D
----- Display/change direction.............................. D D C
----- Display/change the rate ............................... D D C
----- Display/change the meter stop mode .......... D D C
----- Display/switches to the drawback screen .... P P C
The following screens are accessible from
this screen based on the system status.
Prime .................................................................... P P P
Setup A ................................................................ P P P
Get Recipe ........................................................... P P P
Agitate .................................................................. P P P
Setup C ................................................................ P P P
