IVEK DIGISPENSE 3009 - Page 55

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-55
29 October, 2019 IVEK Corp. P03R017E
3.4.7.9 Setup D Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 SETUP D <— status —>
2 RS232/USB BAUDE RATE = 9600 BAUD
3 RS485 BAUDE RATE = 9600 BAUD
4 COMM ADDRESS = 1
5 COMM GATEWAY = DISABLED
6
7
8
9
10
11
12
13
14 SETUP C SETUP E
15 SCREEN SCREEN
----- Displays the Controller Module Status ........ D D D
----- Display/change the RS232/USB baud rate . D D C
----- Display/change the RS485 baud rate .......... D D C
----- Display/change the comm address ............. D D C
----- Display/change the comm gateway ............. D D C
The following screens are accessible from
this screen based on the system status.
Setup C ................................................................ P P P
Setup E ................................................................ P P P
