DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-62
29 October, 2019 IVEK Corp. P03R017E
Auto Trig Screen Description - The Auto Trig screen displays the information for Auto Trigger and allows a user with
Supervisor permission to change the parameters. The current permission level determines which push-buttons are
available as shown. Refer to section 3.3.1.3 for a description of Auto Trig.
The Start push-button is not functional, but the Stop push-button is functional while this screen is visible.
Status - The status indicates the operational state of the system. Refer to section 3.3.8 for an explanation of each
status type.
Auto Retrigger - The Auto Retrigger setting indicates the current mode of the trigger. The mode can either be
Disabled, Count or Infinite. (Refer to section 3.3.1.3)
Retrigger Dwell - The Retrigger Dwell indicates the amount of time in seconds between a dispense and the next auto
retrigger. The range is 0.0 seconds to 300.0 seconds with an increment value of 0.01. (Refer to section 3.3.1.3)
Dispense Count - The Dispense Count indicates the total number of dispenses to be triggered. The range is 2 to
65535 with an increment value of 1. (Refer to section 3.3.1.3)
To change a value;
1. Press the Arrow push-buttons to highlight the parameter.
2. Press the Enter push-button to bring up either the Select New Value or Enter New Value screen.
3. In the Select New Value screen use the up and down arrow push-buttons to select the value. In the Enter New
Value screen press the Minimum or Maximum push-buttons to select the desired value or use the left and right
arrow push-buttons to select the digit and the up and down arrow push-buttons to change the digit's value.
4. Press the Enter push-button.
NOTE
Auto Trig settings only affect Dispense Mode operation. Auto Trig settings do not affect Meter Mode, Prime
Mode, or Agitate Mode operation.
