IVT AE-X12JR-N User Manual

AYXP12JHRN
2 – 8
2.2. Printed wiring board
From Compressor (R)
(Orange)
From Compressor (C)
(White)
From Compressor (S)
(Red)
To Reactor
(Gray)
From Fan
Motor
To Reactor
(Gray)
From 4 Way Valve
From Expansion
Valve
From Thermistor
To Terminal Board
(1) (Brown)
To Terminal Board
(N)(Blue)
To Control Box
(Green/Yellow)
To Terminal Board
(2) (Red)
From Terminal
Board
