IVT AE-X12JR-N User Manual

AYXP12JHRN
2 – 11
1.17. Adjusting the air flow direction
1.17.1 Vertical air flow direction
1.17.2 Horizontal air flow direction
1
Press the VERTICAL AIR FLOW button
to set the desired air
flow direction.
AUTO mode
AUTO obliquely downward
HEAT mode
AUTO obliquely downward downward
COOL/DRY mode
AUTO obliquely upward obliquely downward
1
1
Press the HORIZONTAL AIR FLOW but-
ton to set the desired air
flow direction
CAUTION:
Never attempt to adjust the open panel and the lou-
vres manually.
• Manual adjustment of the open panel and the
louvres can cause the unit to malfunction.
1
TIPS ABOUT AIR FLOW DIRECTION “AUTO“
COOL mode
The open panel will be set obliquely
downward for 10 minutes, and then
shift to obliquely upward to deliver
cool air to the ceiling.
HEAT mode
The open panel will be set obliquely
backward when outlet air tempera-
ture is low, and then shift to obliquely
downward when outlet air becomes
warm. When the room becomes
warm, it will be set downward to de-
liver the warm air to the
floor.
DRY mode
The open panel will be set obliquely
upward.
10 minutes later
When outlet air
temperature is low
When outlet air
becomes warm
When room
becomes warm
