IVT AY-XP12FR-N - Part Names: Indoor and Outdoor Units; Indoor Unit Components; Outdoor Unit Components

E-3
1 AUX. Button
2 Inlet (Air)
3 Open Panel
4 Deodorant Dust Collection
Filter
(non-washable)
5 Air Filters
6 Indicator
7 Receiver Window
8 Vertical Adjustment Louvres
9 Horizontal Adjustment
Louvres
0 Outlet (Air)
q Power Supply Cord
w Remote Control
e PLASMACLUSTER Lamp
(blue)
r TEMPERATURE INDICATOR
t OUTDOOR Temp. Lamp
(green )
y ROOM Temp. Lamp
(green )
u FULL POWER Lamp
(green )
i TIMER Lamp (orange )
o OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
p Inlet (Air)
a Refrigerant Tube and
Interconnecting Cord
s Drainage Hose
d Outlet (Air)
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
i
o
p
a
s
d
PART NAMES
