8
EN
Instruction manual
PART LIST
1. Clutch lever
2. Depth regulator
3. Recoil starter
4. Engine
5. Belt
6. Gear box
7. Blades
8. Height adjuster
9. Shift lever
10. Handlebar
11. Throttle lever
12. On/Off switch
13. Wheel
14. Front wheel
15. Choke lever
16. Oil ller cap
17. Fuel tank
18. Fuel tank cap
19. Air lter
20. Fuel valve
21. Oil drain plug
22. Fuel sediment cup
23. Spark plug
24. Spark plug cap
25. Fender
26. Bumper
CONTENT OF THE BOX
Instruction manual (1 pc), blades assembly (1 set), side
disc (2 pc), wheel (1 set), tool kit (1 set), oil lling funnel
(1 pc).
INTENDED USE
This tool is intended for tilling the supercial layer of the
soil. It’s particularly used for tilling small plots of land
and for horticultural gardening. They replace the work
traditionally done manually with spade and hoe.
TOOL SPECIFICATIONS
Model GTIL-6090-RC
Rated power [W] 3650
No-load speed [RPM] 3600
Displacement [cc] 196
Engine power [HP] 6.5
Nr. strokes of the engine 4
Type of engine cooling air cooling
Starting system recoil starter
Driving mode belt
Numbers of gears -1 / 0 / 2 / 1
Employed fuel unleaded gasoline 90#
Employed oil SAE10W-30
Fuel tank capacity [L] 3.6
Oil tank capacity [L] 0.6
Transmission oil capacity [L] 1.5
Fuel consumption [g/kWh] 395
Tilling depth [mm] 150 - 300
Tilling width [mm] 600 - 900
Number of rotary blades 24 + 2 discs
Wheel type 3,5-4 V
Vibration level (at grip) [m/s
2
] 13 (K=1.5)
Sound pressure level [dB(A)] 102 (K=3)
Sound power level [dB(A)] 48.2 (K=3)
Weight [Kg] 45
