Settings
6 720 645 172 (2010/07) en
15
Setting Factory Range HP
Additional heat
Additional heat type No additional heat
Comp. + add. heat
No additional heat
Internal add. heat
District heating
Modulated add. heat
Mixed add. heat
Only additional heat
Comp. + add. heat
Only compressor
E21
B Set applicable Additional heat type and desired additional heat operation. In District heating
is shown:
Settings
Start E51
Hysteresis
Delay
Actual v.:
3 K
180 °min
Display, can be changed
E21
Stop E51
Delay
Actual v.:
10°min
Display, can be changed
PID E51
P:
I:
D:
T1, Sp, Out
1
100
0
Display
B Set conditions for engaging/disengaging the additional heat.
B Set values for mixing valve control.
Actual and set point value for T1 is shown. In addition the output signal is shown in %.
ECO-drive
ECO-drive
Start
Stop after
No
22:00
6 hr
No, Yes
00:00 - 23:59
E21
B Indicate Yes if activation of the additional heat is to be delayed during a set time period.
The delay increases by 25%.
Tab. 34 Additional heat District heating
