5.7 Resistance table PT1000 temperature sensor
°C Ω °C Ω °C Ω °C Ω °C Ω
-20 921.6 9 1035.1 38 1147.7 67 1259.2 96 1369.8
-19 925.5 10 1039.0 39 1151.5 68 1263.1 97 1373.6
-18 929.5 11 1042.9 40 1155.4 69 1266.9 98 1377.4
-17 933.4 12 1046.8 41 1159.3 70 1270.7 99 1381.2
-16 937.3 13 1050.7 42 1163.1 71 1274.5 100 1385.0
-15 941.2 14 1054.6 43 1167.0 72 1278.4 101 1388.8
-14 945.2 15 1058.5 44 1170.8 73 1282.2 102 1392.6
-13 949.1 16 1062.4 45 1174.7 74 1286.0 103 1396.4
-12 953.0 17 1066.3 46 1178.5 75 1289.8 104 1400.2
-11 956.9 18 1070.2 47 1182.4 76 1293.7 105 1403.9
-10 960.9 19 1074.0 48 1186.2 77 1297.5 106 1407.7
-9 964.8 20 1077.9 49 1190.1 78 1301.3 107 1411.5
-8 968.7 21 1081.8 50 1194.0 79 1305.1 108 1415.3
-7 972.6 22 1085.7 51 1197.8 80 1308.9 109 1419.1
-6 976.5 23 1089.6 52 1201.6 81 1312.7 110 1422.9
-5 980.4 24 1093.5 53 1205.5 82 1316.6 111 1426.6
-4 984.4 25 1097.3 54 1209.3 83 1320.4 112 1430.4
-3 988.3 26 1101.2 55 1213.2 84 1324.2 113 1434.2
-2 992.2 27 1105.1 56 1217.0 85 1328.0 114 1438.0
-1 996.1 28 1109.0 57 1220.9 86 1331.8 115 1441.7
0 1000.0 29 1112.8 58 1224.7 87 1335.6 116 1445.5
1 1003.9 30 1116.7 59 1228.6 88 1339.4 117 1449.3
2 1007.8 31 1120.6 60 1232.4 89 1343.2 118 1453.1
3 1011.7 32 1124.5 61 1236.2 90 1347.0 119 1456.8
4 1015.6 33 1128.3 62 1240.1 91 1350.8 120 1460.6
5 1019.5 34 1132.2 63 1243.9 92 1354.6 121 1464.4
6 1023.4 35 1136.1 64 1247.7 93 1358.4 122 1468.1
7 1027.3 36 1139.9 65 1251.6 94 1362.2 123 1471.9
8 1031.2 37 1143.8 66 1255.4 95 1366.0 124 1475.7
Tab. 50 Measurement values for temperature sensor
