Iwata High Performance Plus Series - Troubleshooting Common Issues; Bubbles in Color Cup or Bottle; Double Line; Not Spraying

TROUBLESHOOTING PROCEDURES
5
SYMPTOM PROBLEM SOLUTION
Bubbles in Color
Cup or Bottle
Loose nozzle cap Tighten nozzle cap (#1B) finger tight
Improper nozzle to head nozzle base connection* See head system (#1) to reseat the nozzle
Cracked or damaged nozzle See head system (#1) to replace the head system
Double Line Dried paint on needle tip (tip-dry) See Cleaning the Needle
Dirty airbrush See Cleaning the Airbrush Between Colors
See Cleaning the Needle
Debris on nozzle tip See head system (#1) and clean the nozzle (#1C)
Bent needle See needle (#10) to replace needle
Cracked or damaged nozzle See head system (#1) to replace the head system
Not Spraying Loose needle chucking nut Finger tighten
Needle stuck Pull out / break free the needle
Improper air pressure See specific compressor instructions to raise or lower
the air pressure
Paint too thick See Paint Preparation
Clogged nozzle See head system (#1) and clean the nozzle (#1C)
Cracked or damaged nozzle See head system (#1) to replace the head system
Skipping Dried paint on needle tip (tip-dry) See Cleaning the Needle (page <?>)
Paint too thick See Paint Preparation (page <?>)
Improper nozzle to head nozzle base connection* See head system (#1) to reseat the nozzle
Dirty airbrush See Cleaning the Airbrush Between Colors (page <?>)
See Cleaning the Needle (page <?>)
Cracked or damaged nozzle See head system (#1) to replace the head system
Spattering Dried paint on needle tip (tip-dry) See Cleaning the Needle
Paint build-up in crown cap Unscrew (#1A) and clean
Air pressure too low See specific compressor instructions to raise the air
pressure
Paint too thick See Paint Preparation
Dirty airbrush See Cleaning the Airbrush Between Colors
See Cleaning the Needle
Main Lever Sticks
(Back and Forth)
Dirty airbrush See Cleaning the Airbrush Between Colors
See Cleaning the Needle
Main Lever Sticks
(Up and Down)
Paint on air valve packing o-ring (#14B) See Lubricating the Air Valve O-Ring
CAUTION
WARNING
* The most likely time to damage the nozzle (#1C) is upon removal from the airbrush. Because the head system can be removed entirely, the
nozzle does not need to be removed at all. If the nozzle is never removed, you do not have to worry about “improper nozzle to head nozzle
base connections”.
