HUEN
HSt ArF
Display Description Value
SEL Electrode style E13: rutile electrode
E18: basic electrode
E10: cellulose electrode
HSc Hot start current 0~10
HSt Hot start time 0~10
ArF Arc Force -10~10
3.2.3 Operation instruction under LIFT TIG mode.
a) When welding stops, press the[STICK/LIFT TIG and VRD switch key] quickly, the LIFT TIG indicator
lights up, and it turns into LIFT TIG mode, the front panel displays as Chart 3.
LIFT TIG means the tungsten contacts the workpiece rst, and then press the torch switch, the
arc is ignited by lifting the torch.
b) [Welding current display] shows the preset current“080”, its unit is ampere(A).
Notes: These machine adopts contact ignition way under TIG mode.
Tap the tungsten electrode to the work piece and then lift up from 2-5 mm. Then the arc is
formed and start welding.
080
Chart 3: display under LIFT TIG mode
9
