25
Chapter 2 Feature
(3-pin jumper provide H/W & S/W protection)
Supports “AC-Loss Recovery”
Supports Suspend to Disk
Supports Suspend to RAM
(DRAM should not have power during S4/S5 state)
Supports Manually Assign PCI IRQ
Supports Auto-reboot function when system hang
Supports PS2 mouse and PS2 keyboard auto swapping
Power requirement
Onboard DC/DC switching voltage regulator supports VIO up to 10A
current
Descrete voltage regulator for AGP port
Supports adjustable VIO (Normal/Increase 5%/Increase 10%,
Normal=3.4V, jumper)
Supports 20A/us Icc slew rate
Supports 8A/us VTT slew rate
Others
ATX Form Factor 305mm x 220mm
