28
Chapter 3 Hardware Setup
Step1:
Locate the ZIF socket and open it by first pulling the lever of
socket upward.
Step2:
Insert the CPU into the socket. Please keep the lever right angle
when inserting CPU.
Step3:
When inserting the CPU please note the correct orientation as
shown. The notched corner should point toward the end of the
lever.
