J.P. Instruments EDM-830 User Manual

For Your Safe Flight Page 43
Scanner Parameter Example Table
Switch Parameter Example Comments
T, A
Voltage, System Bus
14.2 BAT
Battery voltage
T, A
Outside Air Temp
81 OAT
°F or °C
T, A
Induction Air Temp
125 IAT
Out of intercooler
T, A
Compressor Discharge
Temp
300 CDT
Out of compressor
T, A
Intercooler efficiency
25 C-I
Amount of cooling provided
by the intercooler (if
equipped)
T, A
Carburetor Temp
-22 CRB
Not available when CDT is
installed
T, A
Difference between
hottest and coldest EGT
80 DIF
Dot indicates most widely
deviating cylinder
T,A,F
RPM MAP for 1 sec
RPM 2450 MAP 23.4
RPM and Manifold pressure
F, A
Fuel Remaining
CALCULATED
37.2REM
In gallons, liters or pounds
or kilograms
F, A
Fuel required to next
GPS WPT or
Destination
25.9REQ
Present with GPS interface
Valid signal and way point
F, A
Fuel Reserve at next
GPS WPT or
Destination
CALCULATED
11.3REM
Present with GPS interface
Valid signal and way point
F, A
Nautical Miles per Gal
13.0MPG
Present with GPS interface
and valid signal or MPK,
MPL, MPP
F, A
Time to Empty
CALCULATED
02:45H:M
Hours: Minutes Remaining
at current fuel burn
F, A
Fuel Flow Rate
13.5GPH Or KPH, LPH, PPH
F, A
Total Fuel Used
26.5USD
Since last refueling or trip
total.
T, A
EGT, CHT
EGT 1340 CHT 376
EGT, left, CHT, right. Dot
indicates cylinder
T, A
TIT, Turbine Inlet Temp 1
1370TIT
Turbine Inlet Temp #1
T, A
TIT, Turbine Inlet Temp 2
1340TI2
Turbine Inlet Temp #2
T, A
Oil Temp
178OIL-T
Oil Temperature
T, A
Oil Pressure
52OIL-P
Oil Pressure
T, A
Shock Cooling
-30CLD
Cyl. I.D. box indicates
fastest cooling cylinder
