Installthetoiletseatandlidassemblyonthechinabowl
withthefastenersprovidedandpositionthetoiletinits
desiredlocation.Whenlocatingthetoilet,ensurethere
isadequateclearanceabovethebowlsotheseatand
lid assembly can rotate to its fully open position and
remain open on its own. Once the exact position has
been determined, mark the location of the two toilet
mounting holes on the toilet mounting surface and
move the toilet temporarily out of the way. When
securingthetoilettoaplywoodunderlaymentbelowa
layeroffiberglass,toavoidcrackingthefiberglass,drill
a5/16"(8mm)holethroughjustthefiberglasslayerto
provideclearanceforthescrewthreadsandshank.Drill
a3/16"(5mm)pilotholetoacceptthethreadedportion
ofthetoiletholddownscrewsetprovided.Itisgenerally
besttowaituntilthetoiletisreadytobeinstalledforthe
finaltimebeforescrewingtheholddownscrewsintothe
mountingsurface.
The PAR-MAX pump should be mounted to a solid
mounting surface. It should be secured with four
fastenersthroughtherubbergrommetsthatsnapinto
the pump’s base. Do not over-tighten the mounting
screwsandcrushthegrommetssuchthattheywillnot
absorb vibration. The pump may be mounted in any
position;however,ifmountingittoaverticalsurfaceit
shouldbeorientedsowaterdrippingfromalooseport
connection will notdripdownonthemotor. Plumbing
runsshouldbekeptasshortandstraightaspossible.
Allplumbingshouldbecompletedwithquality3/4"(19
mm)hosethatwillnotcollapseorkink.Routetheinlet
hosefroma3/4"(19mm) throughhullandseacock
fittinglocatedwellbelowthewaterline(andwellforward
ofanydischargethroughhulls,ifinstalled)tothepump
inletport.
Ensure the inlet hose passes through an accessible
location(preferablyabovethevessel’swater-line)that
will allow for the installation of the Toilet Pumpgard
strainer where it can be periodically inspected and
cleaned of debris. The Pumpgard strainer should be
securedwithtwofastenerstoasolidmountingsurface
withtheflowarrowpointingtowardsthepump.Theinlet
hose should be cut and each end attached to the
strainer’s ports. Connect the hose from the discharge
portofthestrainertothePAR-MAXpump’sinletport.
Connect another length of hose from the pump’s
dischargeporttotheareaatthebackoftheDesigner
StyledToilet withadequatelengthto connectwiththe
3/4"(19mm)hosebarbatthebackofthechinabowl.
DANGER
!
CAUTION
!
WARNING
!
WARNING
Floodhazard.Iftoiletisinstalledbelowthewaterline
ormaybebelowthewaterlineatanyangleofheelor
trim, it must be intalled with properly positioned
ventedloops.Failuretodosocanresultinflooding
whichcancauselossofpropertyandlife.
Ifthetoiletisinstalledbelowthevessel’swaterline,inorder
topreventasiphonactionfromfillingthetoilet,aproperly
positioned ventedloop fitting must be installed between
thePAR-MAXpumpandthebackofthetoiletbowl.
The vented loop fitting must be secured in a location
thatremainsatleast6-8inches(15-20cm)abovethe
waterlineatallanglesofheelandtrim(seediagram).
Thetoiletdischargeportissizedfor1"(25mm)hose.
Thedischargehoseshouldbeaqualitygradereinforced
hosesuitableforwasteapplications.Routethedischarge
hosetotheholdingtankinthemostdirectwaywithas
fewbendsaspossible.Toretainsomewaterinthebowl,
itisbesttoloopthedischargehoseupabout8-10inches
(15-20cm)asclosetothetoiletaspracticalthenonto
the holding tank. Providing adequate length of hose to
includesuchaloopalsowillprovidetheabilitytomovethe
toiletoutawayfromthebulkheaditbuttsagainsttocomplete
thehoseconnections.Itisbesttoavoidanydipsorlowspots
inthedischargeplumbingthatcanactaswatertrapsand
collectwaste.Ifthisoccurs,wastecansolidifyandcausea
dischargeblockage.
DANGER
!
CAUTION
!
WARNING
!
WARNING
Floodhazard.Iftoiletisinstalledbelowthewaterline
ormaybebelowthewaterlineatanyangleofheelor
trim, it must be intalled with properly positioned
ventedloops.Failuretodosocanresultinflooding
whichcancauselossofpropertyandlife.
Heeled Waterline
Waterline
Vented Loop
Heeled Waterline
Waterline
Vented Loop
