JAC S1 User Manual

correctpositionofengineoilbefore
drain,andthenloosenthedrainplug.
4.Aftertheengineoilhasbeen
completelydrained,tightenthedrain
plugclockwise.
5.Removetheoilfilter.Itshouldbe
removedwithhands (ifyoufeelslip鄄
pery,trytotakeitoffwithapieceof
cloth).Acertainamountofengineoil
mayflowoutwhenthefilterisre鄄
moved.Therefore,alignitwitha
containerbelow.
6.Installthenewoilfilter.Neverover
tightenit,keepthecontactsurface
clean,andcompletelyremoveold
washers.Beforefitting,applyclean
engineoilontothesealingwashers
ofthefilter.
7.Filltheenginewithoilofqualified
gradeandcheckthelevel.
8.Starttheengineandcheckforany
oilleakageatthedrainplugoroilfilter.
9.Aftertheenginehasreachedthe
normalwatertemperature,stopit
andchecktheoillevelagain.
Inspectionandreplacementofen鄄
ginecoolingliquid.
Note:
音 Whenitisnecessarytoadd
engineoil,usetheoilwithquali鄄
fiedgrade.Itisrecommendedto
storetheengineoilinasealed
container,andbuyitfromagas
station.Neverpourtheoilonto
groundordiscarditwithotherdo鄄
mesticrubbish.
Maintenancebyvehicleowner
114
Warning院
音 Takecarewhendrainingthe
engineoil,toavoidscaldingby
hotoil!
Warning院
音 Persistentskincontactwith
usedengineoilmayleadto
cancer.Washtheskinwithsoap
andcleanwater,andprotect
yourskin.
Warning院
音 Neveropenthewatertank
capwhentheengineishot.The
pressureinthecoolingsystem
ofenginemayforcethecooling
liquidout.Failuretoobservethis
advice may result in serious
scalding accident. Therefore,
neveropenthewatertankcap
whentheengineishot.
Enginecoolingliquid
Useanethyleneorethyleneglycol
coolingliquidwithwateratamixture
ratioof50/50.Theenginecooling
liquidshouldbecompatiblewiththe
partsofaluminumalloyengine.Nev鄄
eruseadditionalinhibitororadditive.
Thecoolingsystemshoulduseden鄄
ginecoolingliquidwithcorrectcon鄄
centrationandanti-freezingandan鄄
ti-corrosionperformance.
Donotuseacoolingliquidsolution
withconcentrationexceeding60%or
below35%.Usingsuchcoolingliq鄄
uidmaydamagethecoolingsystem.
Refertothetablebelowforfillingor
replacingenginecoolingliquid,and
adjustthemixtureratioasappropri鄄
ate.
Checkthecoolingliquidlevel
Thecoolingliquidlevelcanbeseen
onthesideoftheplasticcoolingliq鄄
uidtank.Thelevelshouldbebe鄄
tweenthe"L"and"F"lines.Ifitisbe鄄
lowthe "L" mark, cooling liquid
shouldbeadded.Ifthestandardlim鄄
itisstillnotreached,checkforpos鄄
sible water leakage. If the level
keeps on decreasing, have it
checkedbyaJACdealerandfind
outitscause.
Replaceenginecoolingliquid
Replaceenginecoolingliquidasper
themaintenanceschedule.
Protection 益
Mixingratio
Coolingliquid
solution
Water
-15 30% 65%
-25 40% 60%
-35 50% 50%
-45 60% 40%
115
