Jack JK-T718E - Page 46

序号 注解 件号 数量
NO. Note Part NO.
Q
t
y
1
40209007
针杆架滑块 NEEDLE BAR CONNECTION SLIDE BLOCK 1
2 402S30014 滑块销螺钉 STUD 1
3 402S16003 螺母 NUT 1
4 40203011 摇杆后轴套 FRAME ROCK SHAFT BUSHING FRONT 1
5 402S14001 螺钉 SCREW 6
6 40222019 O形圈 RUBBER 1
7 40223023 油芯 OIL WICK 1
8 4020200700 摆杆轴组件 FRAME ROCK SHAFT 1
9 40204006 摇杆后轴衬 FRAME ROCK SHAFT BUSHING REAR 1
10 40203012 摆杆曲柄 FRAME ROCK SHAFT CRANK 1
13 40204007 摆杆后柄 FRAME ROCK SHAFT CRANK FRONT 1
14 402S13002 螺钉 SCREW 1
15
--------
0
16 402S20004 轴位螺钉 HINGE SCREW 1
17 402S16004 螺母 NUT 1
18 40204008 针杆摇杆 NEEDLE BAR PITMAN 1
19
40212025
摆杆连接导板 ROCK SHAFT CONNECTION GUIDE 1
20
S05049
螺钉M4×14 SCREW 2
21 402S30015 螺钉 SCREW 1
22 402S16005 螺母 NUT 1
23 4022500400 针驱齿轮组件 NEEDLE DRIVING GEAR 1
24 40208002 挡圈 THRUST COLLAR 1
25 402S14006 螺钉 SCREW 2
26
--------
0
27 40203013 切刀驱动轴 CAM SHAFT 1
28
12923018
油线 OIL WICK 1
29 402S30016 螺钉 SCREW 1
30 40208003 挡圈 THRUST COLLAR 1
31
S09011
螺钉 SCREW 1
32
40201007 针杆架
NEEDLE BAR FRAME 1
33 402S14001
螺钉 SCREW
1
34 40226014 铰链销 HINGE STUD 1
35
12923018
油线 OIL WICK 1
36 40212027 左固定片 RETAINER LEFT 1
37 402S11010 螺钉 SCREW 2
38 40223009 油毡 FELT 2
39 40212028 油线高端固定板 OIL FELT RETAINER HIGH 1
40 402S11022 螺钉 SCREW 2
41 40205006 针杆连接杆 NEEDLE BAR CONNECTION 1
41-1 402S11010 螺钉 SCREW 1
42
--------
0
43 40212029 油线底端固定板 OIL FELT RETAINER LOWER 1
44 40202057 针杆 NEEDLE BAR 1
45 40213001 针杆导线架 NEEDLE BAR BOBBIN THREAD GUIDE 1
46 101S11006 螺钉 SCREW 1
47 40217002 机针12# NEEDLE DP×5 5
48 40212030 右固定片 RETAINER RIGHT 1
49 402S11010 螺钉 SCREW 2
50
40209028
固定导片 POSITION BRACKET 1
51 40203014 针杆套筒 NEEDLE BAR BUSHING 1
52
--------
0
53 40203015 针杆套筒 NEEDLE BAR BUSHING 1
54 40211005 油毡架 OIL FELT RETAINER 1
55 40226015 轴心 SHAFT 1
56 40223010 油毡 OIL FELT 1
名称 Description
- 10 -
