序号 注解 件号 数量
NO. Note Part NO.
Q
t
y
1 402S30017 线迹宽度调节螺钉 STITCH WIDTH REGULATING SCREW 3
2
402S11034
螺钉 SCREW 1
3 402S16006 螺母 NUT 1
4
N01008
螺母M8 NUT 3
5 40201008 复位杆 REPOSITIONING LEVER 1
6 101S11021 螺钉 SCREW 2
7 40202010 离合杆 TRIPPING ROD 1
7-1 40211006 止动橡皮 STOP RUBBER 1
8 402S30018 螺钉M5×8 SCREW 1
9
B04013
轴承605Z BALL BEARING 1
10
402S30020
调节杆螺钉 REGULATING LEVER STOPPER 1
11 40205007 调节杆连接板 REGULATING LEVER COBBECTION 1
12 40226016 调节销 REGULATING HINGE PIN 1
13 402S20005 轴位螺钉 HINGE SCREW 1
14 40204009 指示曲柄 BELL CRANK 1
15 40209008 滚轮 ROLLER 1
16 402S20006 轴位螺钉 HINGE SCREW 1
17 402S16005 螺母 NUT 1
18 402S30015 螺钉 SCREW 1
19 40212031 刻度指示针 BARRED WIDTH INDICATOR 1
20 101S11006 螺钉 SCREW 2
21 40201009 调节叉杆 REGULATING LEVER 1
22 40227004 弹簧板 SPRING 1
23 101S11006 螺钉 SCREW 2
24 40204038 调节叉杆座 REGULATING LEVER BRACKET 1
25 401S13001 螺钉 SCREW 2
26 40202011 调节杆轴 REGULATING LEVER SHAFT 1
27
12923018
油线 OIL WICK 1
28 40204011 轴承座 BEARING BRACKET 1
29 402S16005 螺母 NUT 2
30 402S30015 紧定螺钉 SCREW 2
31 40202012 针摆复位轴 NEEDLE THROW REPOSITIONING SHAFT 1
32 402S11012 螺钉 SCREW 2
33 40226017 连接销 BEARING BRACKET 2
34
12923018
油线 OIL WICK 2
35 40204012 叉形连杆 REPOSITIONING LEVER LINK 1
36 40226018 连接销 CONNECTING FORKED LINK PIN 1
37
12923018
油线 OIL WICK 1
38 402S30015 螺钉 SCREW 2
39 402S16005 螺母 NUT 2
40 40226019 连接销 CONNECTING STUD 1
41
12923018
油线 OIL WICK 1
42 40227005 弹簧 SPRING 1
43 402S30021 悬挂螺钉 SUSPENSION SCREW 2
44 40204013 叉形连杆 CONNECTING FORKED LINK 1
45 40227006 拉簧 SPRING 1
46 402S16003 螺母 NUT 1
47
402S30020
调节限位螺钉 REGULATING LEVER STOPPER 1
48 40212032 缝宽指示针 SEAM WIDTH INDICATOR 1
49 101S11006 螺钉 SCREW 2
名称 Description
- 12 -
