序号 注解 件号 名称 Description 数量
NO. Note Part NO. Qty
1 40205012 压棒提升拉杆 PRESSER BAR LIFTING ROD LONG 1
2 402S20020 螺钉 SCREW 2
3 402S20021 轴位螺钉 HINGE SCREW 2
4 40205013 前杠杆板 LEVER FRONT 1
5 40204022 链环 LINK 1
6
40229001
开口销2×11 SPLIT PIN 2
7 40205014 后杠杆板 LEVER REAR 1
8 40205015 压棒提升拉杆 PRESSER BAR LIFTING ROD 1
9 40226036 离合杆铰链销 TRIPPING LEVER HINGE PIN 1
10 402S14001 螺钉 SCREW 1
11 402S30035 提升杆限位螺钉 LIFTING LEVER STOPPER 1
12 40201073 压棒提升杆 PRESSER BAR LIFTING LEVER 1
16 SCREW 3
17 BOBBIN WINDER ASM. 1
18
402S11037 绕线器安装螺钉
4023103000 绕线器组件
40211021 绕线器安装座
BOBBIN WINDER BASE 1
20 40202041 绕线器轴 BTW SHAFT 1
21 4020403500 转动曲柄组件 BTW SHAFT BASE 1
22 40210010 转动凸轮 ROTARY CAM 1
23 40235025 转轮 BTW WHEEL 1
24 B04025 轴承686Z BEARING 2
25 40208013 挡圈 BOBBIN BEARING SPACER 1
26 40227045 弹簧 SPRING 1
27 40222034 缓冲橡胶 RUBBER 1
28 40201062 梭心压杆 BTW LEVER 1
29 H05003 E型卡簧5 E-RING 2
30 40228029 垫片 WASHER 2
31 40222033 橡皮圈 BTW WHEEL RUBBER 1
32 40212100 绕线调节板 ADJUSTING PLATE 1
33 40202042 梭心压杆轴 BTW LEVER SHAFT 1
34 40228030 压杆轴垫片 WASHER 2
35 40227044 卡紧弹簧 SPRING 1
36 402S11039 螺钉 SCREW 1
37 402S11040 螺钉 SCREW 1
38 402S14007 紧定螺钉11/64×40 SCREW 3
39 11419001 割线刀 THREAD CUTTER 1
40 SCREW 2
41 BOBBIN THREAD TENSION ASM. 1
42
403S11020 螺钉
4131300
800 夹线器组件
4131301800 过线销 BOBBIN THREAD TENSION ROD ASM. 1
43
41313015
夹线片 THREAD TENSION DISK 2
44
41327017
夹线簧 CONNECTING ROD SPRING 1
45 THREAD TENSION NUT 1
46
101S10019
夹线螺母
413S16012 固定螺母
NUT 11/64-40 1
47 --------
48 40203030 拉杆套管 TUBE 1
