序号 注解 件号 数量
NO. Note Part NO.
t
1 402S30010 压簧调节手柄 PRESSER SPRING REGULATOR 1
2 40202004 压棒 PRESSER BAR 1
3 40227002 压簧 PRESSER SPRING 1
4
40212107
导向支架 GUIDE BRACKET 1
5
--------
0
6 40209003 压棒定位架 PRESSER BAR POSITION BRACKET 1
7 409S14001
内六角平端紧定螺钉 SCREW 1
8 40203010 套管 COLLAR 1
9 40209004 滑动滚轮 SLIDE ROLLER 1
10 40226007 滑动滚轮销 CONNECTING PIN 1
11 40209005 支架 BRACKET 1
12 40212014 安全防护 SAFE DEFEND GUIDE 1
13 402S30011 压棒螺钉 SCREW 1
14 402S11030 螺钉 SCREW 1
14-1 402S11036 螺钉 SCREW 1
15 40212015 导向支架 GUIDE BRACKET 1
16 206S11002 螺钉 SCREW 2
17 206S11002 螺钉 SCREW 2
18 101S11020 螺钉 SCREW 2
19 40212016 面线剪断器导架 NEEDLETHREAD TRIMMER GUIDE 1
20 40212017 面线剪断器导架 NEEDLETHREAD TRIMMER GUIDE 1
21 40216001 压脚板座 WORK CLAMP CHECK HOLDER 1
22 40227003 压脚板座弹簧销 WORK CLAMP CHECK HOLDER SPRING 1
23 40212018 压脚弹簧板 WORK CLAMP CHECK SPRING 2
24 40226008 压脚弹簧定位销 WORK CLAMP CHECK SPRING SET PIN 2
25 402S20002 轴位螺钉 HINGE SCREW 1
26 101S11019 螺钉 SCREW 1
27 40216002 压脚板 WORK CLAMP CHECK 1
28 4021600300 压脚板座组件 WORK CLAMP CHECK HOLDER ASM. 1
29
--------
0
30 40212019 送布拖板 STITCH PLATE 1
31 4021202000 支架盖板组件 BRACKET COVER 1
32 402S11007 螺钉 SCREW 2
33 40201004 送料支架 WORK CLAMP ARM BRACKET ASM 1
34 401S12001 螺钉 SCREW 1
35 40205004 压脚臂支架 WORK CLAMP CARRIER BRACKET PITMAN 1
36 402S20003 轴位螺钉 HINGE SCREW 1
37 40202005 压脚臂滑杆 WORK CLAMP ARM SLIDE ROD 1
38 40212023 送布拖板支架导块 WORK CLAMP CARRIER BRACKET GUIDE 1
39 402S11028 螺钉 SCREW 2
40 40201033 布料夹支架 WORK CLAMP BRACKET 1
41 40226010 连接销 CONNECTION PIN 1
42 402S11009 螺钉 SCREW 1
43 40204031 拖架 BEARING ARM 1
44 402S14006 螺钉 SCREW 1
45 402S30016 螺钉 SCREW 1
46 402S30013 螺钉 SCREW 1
47 40212024
调节送料长度轴导板 LENGTH REGULATING SHAFT GUIDE
1
48 402S16003 螺母 NUT 1
49 4020400400 调节送料长度刻度盘组件 LENGTH REGULATING SCALE ASM. 1
50 40205005 送料臂 BELL CRANK 1
51
S05040
螺钉M6×16 SCREW 1
52 40209006 滚子 ROLLER 1
53 40226012 曲柄滚子销 BELL CRANK ROLLER STUD 1
54 402S16003 螺母 NUT 1
名称 Description
