Jack W4 Series User Manual

Rockover switch
warning
Adjust the machine head until it stops warning
5LEEP
休眠
sleep
关闭系统电源，30 秒后重新接通电源，控制器若仍不能正常工作，请更
换控制器并通知厂方。
Turn off the machine, and turn on it after 30 second，if the control
box still not work，please replace the control box and inform
service center.。
3.4 故障代码表(
breakdown code table)
若系统出现报错或报警，请首先检查如下项：(
If the system report error or warning
，
please check the following
first
：
)
1、先确认机器的连接线是否连接完好；2、确认电控和机头是否匹配；3、确认恢复出厂是否已经恢复完成。
1
、
whether all the connection is fine
；
2
、
make sure the electric control and machine head are matching
；
3
、
make
sure the system already reset。
故障代码
Error code
代码含义
Description
解决措施
Way to solve
E r r - 0 1
硬件过流
Hardware overcurrent
关闭系统电源，30 秒后重新接通电源，控制器若仍不能正常工作，请更换
控制器并通知厂方。Turn off the machine, and turn on it after 30 second，if the
control box still not work ， please replace the control box and inform service
center
E r r - 0 2
软件过流
Software overcurrent
E r r - 0 3
系统欠压
System under voltage
断开控制器电源，检查输入电源电压是否偏低（低于 176V）。若电源电压
偏低，请在电压恢复正常后重新启动控制器。若电压恢复正常后，启动控制
器仍不能正常工作，请更换控制器并通知厂方.
Disconnect power of control
box
，
check whether the power voltage is low
（
lower than 176V
）
. If the power
voltage is low
，
restart the control box when voltage get it right. If still not work,
please replace the control boxes and inform service center
E r r - 0 4
停机时过压
Down time overvoltage
断开控制器电源，检查输入电源电压是否偏高（高于 264V）。若电源电压
偏高，请在电压恢复正常后重新启动控制器。若电压恢复正常后，启动控制
器仍不能正常工作，请更换控制器并通知厂方
Disconnect power of control
box
，
check whether the power voltage is high
（
higher than 264V
）
. If the power
voltage is low
，
restart the control box when voltage get it right. If still not work,
please replace the control box and inform service center
E r r - 0 5
运行时过压
Operation overvoltage
E r r - 0 6
电磁铁回路故障
Magnet circuit fault
关闭系统电源，检查电磁铁连线是否正确，是否有松动、破损等现象。若有
则及时更换。确认无误后重启系统，若仍不能工作，请更换控制器并通知厂
方。
Power off
，
check the connection of magnet
，
whether loose or break
。
Replace
it if it loose or break, then restart the system
，
If still not work, please replace the
control boxes and inform service center
E r r - 0 7
电流检测回路故障
Current detection circuit
fault
关闭系统电源，30 秒后重新接通电源观察是否能正常工作。重试几次，若
该故障频繁出现，请更换控制器并通知厂方。Power off, Restart after 30
second, check whether it can work normally. Try again a few times，If the error
occurred frequently, please replace the control boxes and inform service center
E r r - 0 8
电机堵转
Motor locked rotor
断开控制器电源，检查电机电源输入插头是否脱落、松动、破损，是否有异
物缠绕在机头上。排除后重启系统仍不能正常工作，请更换控制器并通知厂
方 。 Power off, Check whether the motor power plug fall off, lose, or break.
Whether any foreign matter twist on machine head. Restart after check and
repair. If still not work, please replace the control boxes and inform service
center
E r r - 0 9
制动回路故障
Brake circuit breakdown
关闭系统电源，检查电源板上白色的制动电阻接头是否松动或脱落，将其插
紧后重启系统。若仍不能正常工作，请更换控制器并通知厂方。Power off，
check the connection of white resistance on power panel. Whether falloff or lose,
restart after plug in. If still not work, please replace the control boxes, and inform
service center.

Jack W4 Series Specifications

General

Number of Threads	3 or 4
Type	Overlock
Lubrication	Automatic
Motor	Servo motor
Stitch Types	Overlock
Bobbin	None (uses loopers)
Speed	Adjustable
Presser Feet	Standard Overlock Foot
