Jackery Explorer 300 Plus - Technical Specifications

Product Name
Model No.
Peak Power (Pm)
Dimensions (unfolded)
Dimensions (folded)
Weight
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
Power Voltage (Vm)
Power Current (Im)
Operating Temperature Range
Jackery SolarSaga 40 Mini
JS-40A
40W±5%
Around 1020×300×18.5mm
Around 252×300×30mm
Around 2.6 Ibs / 1.2 kg
25V±5%
2.07A±5%
20.9V±5%
1.91A±5%
-20~65℃（-4~149℉）
STC (1000W/㎡, 25℃, AM 1.5).
Congratulations on your new Jackery Explorer 300 Plus. Please read this manual carefully before using the
product, particularly the relevant precautions to ensure proper use. Keep this manual in an accessible
place for frequent reference.
In compliance with laws and regulations, the right of final interpretation of this document and all related
documents of this product resides with the Company.
Please kindly notice that no further notifications will be given in case of any update, revision or termination.
CERTIFICATIONS
※ USB Type-C and USB-C are registered trademarks of USB Implementers Forum.
® ®
01
TECHNICAL SPECIFICATIONS
Product Name
Model No.
Cell Chemistry
Capacity
Weight
Dimensions
Cycle Life
Total Output
AC Output
USB-A Output
USB-C (OUT)
USB-C (IN/OUT)
USB Total Output
Car Port
Charge Mode AC Input
Bypass Mode AC Input/Output
DC Input(USB-C)
Charge Temperature
Discharge Temperature
Jackery Explorer 300 Plus
JE-300B
LiFePO4
Lithium-ion 22.5Ah / 12.8V DC (288Wh)
Around 8.27 Ibs / 3.75 kg
9.1 x 6.1 x 6.6 in / 23 x 15.5 x 16.7 cm
3000 cycles to 80%+ capacity
300W
230V~ 50Hz, 1.31A, 300W Rated, 600W Surge peak
15W Max 5V⎓3A
15W Max 5V⎓3A
100W Max 5V⎓3A, 9V⎓3A, 12V⎓3A, 15V⎓3A, 20V⎓5A
USB-C(IN/OUT) : 100W Max, USB-C(OUT)+USB-A : 24W Max
12V⎓10A
220V-240V~ 50Hz, 10A Max
220V-240V~ 50Hz, 300W Max
12-27V⎓5A Max, 100W Max
32℉~113℉ (0°C~45°C)
14℉~113℉ (-10°C~45°C)
