03
Retractable Handle
(Press the button on the retractable
handle and pull to extend)
AC Expansion Port
(Connect to Smart Transfer Switch)
NEMA L14-30R AC Output Port
(120V/240V)
NEMA 14-50 AC Output Port
(120V/240V)
AC Output
Reset Button
Wheels
AC Input
High-PV Switch
(Turns on/off the switch to enable/
disable High-PV solar charging)
DC Expansion Port
Terminal A
(Connect to Battery Pack)
Wheel Brake
Handle
Low-PV Input (8020)
High-PV Input (MC4)
US
Bottom Handle
