Plasma 70 S
Operating Manual Page 16
Item
Designation
1
case frame compl., coated black
2
case top
3
side panel, top left
4
side panel, top right
6
case push-handle incl. assembly parts
7
bonded tired wheel 200 mm d incl. assembly parts
8
front panel ‘Plasma 70 S’
10
master switch S225-647859
control knob for master switch
11
signal element 24 V, yellow
12
signal element 24 V, green
bulb 24V
13
gas test push button, green
14
fuse holder with bayonette type sealing cap
fine-wire fuse T 2 A
15
potentiometer 10 kOhm lin. (cutting current)
potentiometer control knob 36 mm D
16
insert tip jack, BEB 35-50
17
central connecting socket with protection locking
central connecting plug with protection locking
18
mains cable, compl. 4 x 2.5 sq.mm, 5 m, 32A
strain relief screw fitting PG 16 “
19
fan A4E 300, 230 V incl. capacitor + assembly parts
capacitor 1 µF (fan)
fan control board VR 1, 24 V
spacing piece CBS -09A to fasten board
20
cutting transformer with choke incl. cable
21
cutting transformer, incl. cable and thermoswitch
thermoswitch 170° C (break) for cutting transformer
thermoswitch 80° C (make) for cutting transformer
22
smoothing choke, incl. flexible cord
23
HF blocking choke PLD 10, incl. flex and assembly parts
24
Stern resistor 3 Ohm (pilot current) compl.
25
wire resistor 250 Ohm (base load) compl.
26
thyristor set incl. cooling block and connecting lines
thyristor set compl. (repair service)
thyristor protecting unit compl.
thermoswitch 90° (break) for thyristor set
thermoswitch 50° (make) for thyristor set
27
HF starting device SIG 3.2, 24 V
28
HF blocking choke PLD 1
29
HF filter SLF 2
30
HF safety board HFS 1
