Jacobsen AR-522 User Manual

DECALS 2
7
OPERATION
To Start To Stop/Park
To Drive/Transport To Mow
1. Parking Brake...................On
2. Traction Pedal............Neutral
3. Mower Switch...................Off
4. Throttle............................Half
5. Ignition..............................On
6. Glow Plug Light...............Off
7. Ignition...........................Start
1. Follow “To Start”
instructions.
2. Mower Switch...................Off
3. Cutting Units................Raise
4. Parking Brake...................Off
5. Throttle............................Fast
6. Slowly depress
traction pedal.
1. Traction Pedal............Neutral
2. Mower Switch...................Off
3. Parking Brake...................On
4. Throttle...........................Slow
5. Ignition..............................Off
6. Remove Key
1. Follow “To Start”
instructions.
2. Throttle............................Fast
3. Mower Switch.................Mow
4. Parking Brake...................Off
5. Cutting Units................Lower
6. Slowly depress
traction pedal.
READ MANUAL BEFORE OPERATING.
REPLACEMENT MANUAL AVAILABLE FROM:
JACOBSEN TEXTRON - CHARLOTTE, NC
4124445
3/4
1
1-1/4
1-1/2
1-3/4
2
2-1/4
2-1/2
2-3/4
3
3-1/4
3-1/2
3-3/4
4
4-1/4
4-1/2
4-3/4
5
5-1/4
CUT
HEIGHT
W/ 1/2
SPACERS
CUT
HEIGHT
W/ 1/4
SPACER
4133609
3008682
