JACOBSEN
AR3
SAFETY, OP
ERATORS & MAINT
ENANCE MANUAL
10
ACCESSORIES
10.1
OPS
FRAME (LMAC164)
W
ARNING
When an OPS fram
e is fitted to a machine,
a seat belt must be fitted and worn by the
operator.
10.2
TRANS
PORT LATCH KIT (LMAC174)
A transpo
rt latch kit
is availab
le for the fro
nt lift arms
10.3
WORKI
NG LAMP KIT (LMAC163)
A Workin
g lamp kit i
s available
to fit two lam
ps to the
front of
the operator
plateform.
53
55
