69
> Change from previous revision
ECLIPSE
Item Part No. Qty. Description Serial Numbers/Notes
1
4139661
1 Grass Shield, 18 Inch
Used on 63300, 63313, 63327, and
63331
1 4139660 1 Grass Shield, 22 Inch
Used on 63302, 63311, 63325, and
63329
1 4139662 1 Grass Shield, 26 Inch Used on 63304 and 63315
2 4127335 2 • Decal, Danger
3 241828 1 Bracket, Catcher Mounting, R.H.
4 241827 1 Bracket, Catcher Mounting, L.H.
5 2000072 2 Bracket, Roller Adjusting
6 343616 2 Stud, Front Roller Adjusting
7 3005692 2 Adjusting Knob
8 441677 4 Carriage Bolt 5/16-18 x 1-1/2”
9 444718 4 Locknut, 5/16-18 Center
10 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
11 364441 2 Spacer
12 446136 2 Lockwasher, 5/16 Heavy
13 443106 2 Nut, 5/16-18 Hex
14 443102 4 Nut, 1/4-20 Hex
15 352737 2 Set Screw, 1/4-20 x 7/8” Square Hd
16 3008974 4 Grommet
17 400112 2 Screw, 1/4-20 x 1” Hex Head
18 453023 2 Flat Washer, 1/4
19 446130 2 Lockwasher, 1/4 Heavy
To Next Page
