Jacobsen Kubota D1105-E4B User Manual

101
> Change from previous revision
TR320
Item Part No. Qty. Description Serial Numbers/Notes
1
4399768 2 Center Deck
2 452439 2 Hex Nut, M16
3 682228 2 Roller Bracket
4 689626 1 Roller Brace Weldment
5 692158 1 Roller Brace, LH Bracket
6 692159 1 Roller Brace, RH Bracket
7 MBG1642 2 Roller - Wing Cutter Units
8 450192 4 Hex Screw, M8 - 1.25 x 25
9 450216 4 Hex Screw, M10 - 1.5 x 35
10 450390 4 Washer, M8 x 17 x 1.8
11 450391 4 Washer, M10 x 21 x 2.2
12 450393 2 Washer, M16 x 30 x 3.3
13 450868 4 Hex Socket Screw, M8 - 1.25 x 35 Grade 12.9
14 452436 8 Hex Nut, M8
15 452437 4 Hex Nut, M10
16 450081 2 Hex Bolt, M16 - 2 x 130
17 4329226 1 Valve, Hydraulic Wing Arm
