78
> Change from previous revision
TR330
40.1 Front Lift Cylinder
Part Number 669395
Item Part No. Qty. Description Serial Numbers/Notes
1
N/S 1 Cylinder
2N/S1Gland
3N/S1Rod
4 N/S 1 Snap Ring
4369206 1 Seal Kit
5N/S1•O-Ring
6 N/S 1 • Inner Bearing
7 N/S 1 • Seal, Gland
8 N/S 1 • Outer Bearing
9N/S1•Wiper
3
1
2
4
5
6
7
8
9
