25
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
674447 2 Hose Clamp, 40-60 mm
2 3002365 1 Indicator, Air Cleaner
3 4378166 1 Hose, Air Cleaner Intake
4 4378646 1 Bracket, Air Cleaner
5 4395228 1 Rain Cap Includes Clamp
6 450193 2 Screw, M8-1.25 x 30 mm Hex Head
7 450242 3 Screw, M12-1.75 x 35 mm Hex Head
8 452436 2 Nut, M8-1.25 Flange Nyloc
9 452438 3 Nut, M12-1.75 Flange Nyloc
10 819028 1 Mount, Air Cleaner
11 4395230 1 Air Cleaner
5000913 1 • Element, Air Filter
5000912 1 • Cover, Assembly
5000914 1 • Valve, Vactuator
12 450392 3 Washer, M12 x 24 x 2.7
13 450390 2 Washer, M8 x 17 x 1.8
To Next Page
