61
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
4396888 1 26” Center Pivot Arm For 26” US and UK Reels
1 4396986 1 30” Center Pivot Arm
2 002193318 2 • Bushing
3 4396889 1 26” Left Pivot Arm For 26” US and UK Reels
3 4396890 1 26” Right Pivot Arm For 26” US and UK Reels
3 4399255 1 30” Left Pivot Arm
3 4399254 1 30” Right Pivot Arm
4 002193318 2 • Bushing
5 682423 1 Pivot Bracket, Left Side For 26” US Reels
5 4139281 1 Pivot Bracket, Left Side For 26” UK Reels
6 682424 1 Pivot Bracket, RIght Side For 26” US Reels
6 4139349 1 Pivot Bracket, RIght Side For 26” UK Reels
7 001399032 2 Nut, 1/2-20 Nyloc For 26” US and UK Reels
8 001599052 12 Flat Washer
9 400260 12 Screw, 3/8-16 x .875 Hex Head
10 4131749 3 Motor, Reels For US Reels
11 4139374 2 Spacer, Pivot For 26” US and UK Reels
12 4151277 2 Bumper, Lift Arm For 30” US Center Reel
13 4399247 1 Roller, Reel Unit For 26” US and UK Reels
14 4399270 1 Bracket, Reel Unit For 26” US and UK Reels
15 446142 12 Lock Washer, 3/8 Heavy
16 450059 2 Screw, M12-1.75 x 100 mm Hex Head
17 450392 1 Washer, M12 x 24 x 2.7 For 26” US and UK Reels
18 450433 2 Lock Washer, M8 x 15 x 0.8 For 26” US and UK Reels
19 450725 2 Screw, M8-1.25 x 30mm Socket Head For 26” US and UK Reels
20 450866 4 Screw, M8-1.25 x 25mm Socket Head For 26” US and UK Reels
21 452436 6 Nut, M8-1.25 Flange Nyloc For 26” US and UK Reels
22 452438 1 Nut, M12-1.75 Flange Nyloc For 26” US and UK Reels
23 456010577 2 Screw, 1/2-20 x 1 1/2” Hex Head For 26” US and UK Reels
24 4397726 2 Bumper, Lift Arm For 26” US and UK Center Reels
25 4397846 1 Pivot Bracket, Left Side For 26” US Center Reel
26 4397847 1 Pivot Bracket, RIght Side For 26” US Center Reel
27 450400 6 Washer, M8 x 21 x 1.8 For 26” US and UK Center Reel
28 450015 2 Screw, M8-1.25 x 35 mm Hex Head For 26” US and UK Center Reel
29 REF 3 Fitting, -6 ORFS x -4 ORB Straight See 24.1
30 REF 6 Fitting, -8 ORFS x -10 ORB See 22.1
31 450214 1 Screw, M10-1.5 x 25 mm Hex Head For 26” UK Reels
32 450379 1 Nut, M10-1.5 Hex Nyloc For 26” UK Reels
33 450391 2 Washer, M10 x 21 x 2.2 For 26” UK Reels
34 4344103 1 P-Clip, 48 mm Rubber Sleeve For 26” UK Reels
35 MBF0895A.07 1 Assembly, 26” x 7K Cylinder, Left Side For 26” UK Reels
35 MBF0325B.07 1
Assembly, 26” x 7K Cylinder, Right Side
For 26” UK Reels
35 MBF0895A.07 1 Assembly, 26” x 7K Cylinder, Left Side For 26” UK Reels
To Next Page
