85
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
1 Swashplate
21Thrust Plate
3 2 Trunnion BearingKit
4 1 Seal, Shaft Included in seal kit
5 1 Washer, Seal Support
6 1 Retaining Ring, Internal
7 1 35 cc Cylinder Block Kit
8 1 • Guide, Slipper Retainer
9 3 • Pin, Slipper Holddown
10 9 • Piston Assembly, 35 cc
11 1 • Retainer, Holddown Pin
12 1 • Retainer, Slipper
13 1 • Retaining Ring
14 1 • Spring, Cylinder Block
15 1 • Washer
16 1 • Retainer, Spring
17 1 Valve Plate
18 1 Slotted Pin
19 1 Charge Relief Plug
20 4224121 1 • O-Ring
21 1 Shim Kit
22 1 Spring, Charge Pressure
23 1 Poppet
24 1 End Cap w/ loop flushing
25 1 Gasket, End Cap Included in seal kit
26 1 Bearing, Needle
27 4 Screw
28 1 Plug Assembly
29 1 • O-Ring Included in seal kit
30 1 Spring
31 1 Spool
32 1 Neutral Return Arm Assembly
33 1 • Cam Bearing
34 1 • Retaining Ring
35 1 • Spring, Neutral Return
36 1 • Pivot, Neutral Return
37 1 • Nut, Seal Included in seal kit
38 1 Bypass Valve Assembly
39 1 • Back-Up Ring Included in seal kit
40 1 • O-Ring Included in seal kit
41 2 SCR Valve, 280 BAR (4060 psi)
42 1 • O-Ring Included in seal kit
43 1 • O-Ring Included in seal kit
44 1 Trunnion Cover Assembly
45 1 • Seal, Trunnion Included in seal kit
To Next Page
