4 ONDERHOUD
NL-18
4.11 ONDERHOUDSSCHEMA____________________________________________________
Aanbevolen inspectie- en smeerintervallen.
Smeermiddelen
I
- SAE 10W-30, classificatie API SF of SG.
II
- Lithium smeervet NLGI - sterktekwaliteit 2
III
- Lubriplate® smeervet, Jacobsen onderdeelnr. 5001581
IV
- SAE EP-140 olie - aftappen en opnieuw vullen
★
- Dun laagje opbrengen
Dagelijks 20 50 100 300 Jaarlijks Smeermidd.
Luchtfilter.............................................. I........................................ R
Verbrandingskamer ....................................................................................................................R
Motorolie............................................... I...................V........................................ V..........................................
......................I
Brandstofleiding........................................................................................................................................... V - 2 jr
Bougie ................................................................................................................ A/R
Klepspeling.................................................................................................................................A
Smeerpunten (figuur 6A)
1 - Rol...............................................................S................................................................................... S
....................II
2 - Afstelling hoogte............................................................... S
............................................................................................II
3 - Rechter kooias.............................................S......................................................................................
.....................II
4 - Tractierol....................................................... ................... S................................................................ ...................
II
5 - Lager koppelingsas ............................................................................................................................S
...................II
6 - Koppelingsas......................................................................................................................................S
...................III
7 - Koppelingspennen...............................................................................................................................
...................III
★
8 - Tractienaaf............................... ...................S......................................................................................
.....................III
9 - Wiellagers...................................................................................................................... ................... S
....................II
10 - Kooikoppelingshendel ...............................S......................................................................................
.....................II
11 - Kettingkast................................................................................................................... ................... V
................... IV
A - Afstellen of bijvullen R - Reinigen I - Inspecteren S - Smeren V - Vervangen
