16
> Change from previous revision
Item Part No. Qty. Description Serial Numbers/Notes
1
3004026 1 Shaft, Roller
2 163801 2 Gear, Differential
3 325656 2 • Bushing
4 344745 2 Washer, Thrust
5 202947 2 Pinion
6 308030 2 Washer, Pinion Thrust
7 103862 2 Housing, Differential
8 308033 2 • Bushing
9 403723 6 Screw, #10-24 x 5/8” Hex Head
10 444782 6 Locknut, #10-24 Center
11 338394 2 Hub, Roller
12 471214 2 FItting, Grease
13 400190 6 Screw, 5/16-18 x 1-1/4” Hex Head
14 446136 6 Lockwasher, 5/16 Heavy
15 163523 2 Roller, Traction
16 471222 2 • Fitting, Grease
17 304569 2 • Bushing
18 366648 2 • Seal, Grease
19 364171 8 Bolt, Special
20 308028 1 Shaft, Pinion
21 365307 1 Hub
PGM 22
