03/23/05 J600CHT Assembly – DRAFT Prepared for Jacto
Service Seminar 3/2005
DRAFT COPY
PTO Shaft and Clean Water Tank
1) Install the PTO shaft by sliding the implement end over the drive shaft and
aligning the key way with the key. Install the retaining bolt and tighten.
2) Install the clean water tank bracket onto the left frame post as shown below.
Install the clean water tank into the bracket.
