Jacuzzi Comet User Manual

INSTALLING YOUR CLEANER 7
7
1.3 FUNCTION & ADJUSTMENT OF NOZZLE
1.3.1 The COMET features two nozzles, one of which opens while the other closes. Water flows out
through the opened nozzle to drive the cleaner forward. Adjust the direction of travel by rotating the
nozzle.
1.3.2 The nozzle may be adjusted based on the desired route of the cleaner.
Cleaner will move in a straight line when nozzles are positioned at 0°.
Cleaner will move in an arc when set up to 0° to 60°.
NOTE: While the COMET will clean freeform pools, some manual cleaning may be required for
harder-to-reach places.
Figure 1.3.1
Figure 1.3.2
