Jacuzzi DESIGNER BATH SERIES User Manual

ENGLISH
10-1/2"
36"
14"
5-1/4"
42"
72"
3"
18" x 4"*
Motor
Opt. Service
Access
12" H x 18" L Service Access
Heater
REÁL™, Right Hand
SABELLA™ Right Hand
72"
10-1/4"
36"
3"
1"
3"
3"
1"
7"
47"
13-3/4"
18" x 4"
Heater
Motor
Opt. Service
Access
12" H x 18" L Service Access
72"
36"
18"
TORRETTA™ 36, Left Hand
6-3/4"
15" X 4"
Heater
Motor
Opt. Service Access
12" H x 18" L Service Access
15-1/4"
ROUGHING-IN REFERENCE (RECTANGULAR)
Some tubs are supplied with cutout and/or undermount template. Refer to CUTOUT on pages 6-8 for template part numbers.
* Add 1/4" to this dimension when roughing-in for 3-wall niche.
NOTE: 1. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
2. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
3. Service access dimensions given are minimum size.
4. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
ROUGHING-IN REFERENCE
11
Jacuzzi Whirlpool Bath K339000X 3/06
