Jacuzzi DESIGNER BATH SERIES User Manual

ENGLISH
ROUGHING-IN REFERENCE (RECTANGULAR)
Some tubs are supplied with cutout and/or undermount template. Refer to CUTOUT on pages 6-8 for template part numbers.
* Add 1/4" to this dimension when roughing-in for 3-wall niche.
NOTE: 1. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
2. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
3. Service access dimensions given are minimum size.
4. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
10"
35-1/2"
11-3/4"
6"
30-1/8"
42"
66"
4" x 4"
Heater
Motor
12" H x 18" L
Service Access
Opt. Service Access
BELLAVISTA™ 5.5, Right Hand
4" x 4"
42"
72"
10-1/2"
35-13/16"
11-3/4"
6"
30-1/8"
Heater
Motor
12" H x 18" L
Service Access
Opt. Service
Access
BELLAVISTA™ 6, Right Hand
CIPREA™, Right Hand
4"
7"
14" x 4"
*72"
34-1/2"
48"
36"
Motor
Heater
12" H x 18" L
Service Access
7"
32-1/2"
11-3/4
"
6"
30-1/8"
42"
60"
4" x 4"
Heater
Motor
12" H x 18" L
Service Access
Opt. Service Access
BELLAVISTA™ 5, Right Hand
66"
36"
11-15/16"
33"
5" x 5"
8-1/2"
ALLUSION™ 6636, Right Hand
Heater
Motor
12" H x 18" L Service Access
Opt. Service
Access
72"
36"
11-15/16"
36"
5" x 5"
8-1/2"
ALLUSION™ 7236, Right Hand
Heater
Motor
12" H x 18" L Service Access
Opt. Service
Access
72"
42"
11-15/16"
36"
5" x 5"
8-1/2"
ALLUSION™ 7242, Right Hand
Heater
Motor
12" H x 18" L Service Access
Opt. Service
Access
9
Jacuzzi Whirlpool Bath K339000X 3/06
ROUGHING-IN REFERENCE
